 Larva of Ephydridae
|
|
| Abdelsalam |
Posted on 19-04-2019 10:32
|
|
Member Location: Egypt Posts: 21 Joined: 18.04.19 |
Can anyone help me to identify this larva of Ephydridae? These larvae were found associated with the green algae (Ulva fasciata) in the fouling community, these algal mate covered the coastal natural rocks in El-Mex area, west of Alexandria city; Egyptian Mediterranean coast. Waters of sampling site with salinity of 22-24 ‰, moderately exposed area, and with shallow depth. Please look at the attached photo I will attach another photos in reply. |
|
|
|
| Abdelsalam |
Posted on 19-04-2019 10:37
|
|
Member Location: Egypt Posts: 21 Joined: 18.04.19 |
Ventral view of larva (posterior spiracles protruded) |
|
|
|
| Abdelsalam |
Posted on 19-04-2019 10:39
|
|
Member Location: Egypt Posts: 21 Joined: 18.04.19 |
Enlarged dorsal view of larval head showing anterior spines (spinules) & left antenna |
|
|
|
| Abdelsalam |
Posted on 19-04-2019 10:41
|
|
Member Location: Egypt Posts: 21 Joined: 18.04.19 |
Dorsal view of larval head showing anterior spiracles |
|
|
|
| Abdelsalam |
Posted on 19-04-2019 10:43
|
|
Member Location: Egypt Posts: 21 Joined: 18.04.19 |
Enlarged anterior spiracle |
|
|
|
| Abdelsalam |
Posted on 19-04-2019 10:45
|
|
Member Location: Egypt Posts: 21 Joined: 18.04.19 |
Posterior spiracles |
|
|
|
| Abdelsalam |
Posted on 19-04-2019 10:46
|
|
Member Location: Egypt Posts: 21 Joined: 18.04.19 |
Enlarged posterior spiracle |
|
|
|
| Abdelsalam |
Posted on 19-04-2019 10:49
|
|
Member Location: Egypt Posts: 21 Joined: 18.04.19 |
Cephalopharyngeal skeleton |
|
|
|
| Paul Beuk |
Posted on 19-04-2019 13:48
|
 Super Administrator Location: Netherlands Posts: 19403 Joined: 11.05.04 |
Your images don't show. Perhaps check the FAQ? https://diptera.i...p?cat_id=2
Paul - - - - Paul Beuk on https://diptera.info |
 |
|
| Abdelsalam |
Posted on 19-04-2019 16:25
|
|
Member Location: Egypt Posts: 21 Joined: 18.04.19 |
I will upload again |
|
|
|
| Abdelsalam |
Posted on 19-04-2019 16:29
|
|
Member Location: Egypt Posts: 21 Joined: 18.04.19 |
Can anyone help me to identify this larva of Ephydridae? These larvae were found associated with the green algae (Ulva fasciata) in the fouling community, these algal mate covered the coastal natural rocks in El-Mex area, west of Alexandria city; Egyptian Mediterranean coast. Waters of sampling site with salinity of 22-24 ‰, moderately exposed area, and with shallow depth. Please look at the attached photo I will attach another photos in reply. |
|
|
|
| Abdelsalam |
Posted on 19-04-2019 16:35
|
|
Member Location: Egypt Posts: 21 Joined: 18.04.19 |
Ventral view of larva (posterior spiracles protruded) Dear Paul Did the photos have attached or not yet? |
|
|
|
| Paul Beuk |
Posted on 19-04-2019 19:34
|
|
Super Administrator Location: Netherlands Posts: 19403 Joined: 11.05.04 |
Nope
Paul - - - - Paul Beuk on https://diptera.info |
|
|
|
| Abdelsalam |
Posted on 20-04-2019 00:34
|
|
Member Location: Egypt Posts: 21 Joined: 18.04.19 |
Can anyone help me to identify this larva of Ephydridae? These larvae were found associated with the green algae (Ulva fasciata) in the fouling community, these algal mate covered the coastal natural rocks in El-Mex area, west of Alexandria city; Egyptian Mediterranean coast. Waters of sampling site with salinity of 22-24 ‰, moderately exposed area, and with shallow depth. Please look at the attached photo Dorsal view of larva (posterior spiracle protruded) Abdelsalam attached the following image:  [58.79Kb] |
|
|
|
| Abdelsalam |
Posted on 20-04-2019 00:36
|
|
Member Location: Egypt Posts: 21 Joined: 18.04.19 |
Enlarged dorsal tubercle spinose, bearing single sensillum centrally
Abdelsalam attached the following image:  [46.91Kb] |
|
|
|
| Abdelsalam |
Posted on 20-04-2019 00:38
|
|
Member Location: Egypt Posts: 21 Joined: 18.04.19 |
Ventral view of larva (posterior spiracles protruded)
Abdelsalam attached the following image:  [90.65Kb] |
|
|
|
| Abdelsalam |
Posted on 20-04-2019 00:40
|
|
Member Location: Egypt Posts: 21 Joined: 18.04.19 |
The posterior spiracles are proceeding by scale like spines
Abdelsalam attached the following image:  [51.97Kb] |
|
|
|
| Abdelsalam |
Posted on 20-04-2019 00:42
|
|
Member Location: Egypt Posts: 21 Joined: 18.04.19 |
Enlarged dorsal view of larval head showing anterior spines (spinules) & left antenna
Abdelsalam attached the following image:  [85.01Kb] |
|
|
|
| Abdelsalam |
Posted on 20-04-2019 00:44
|
|
Member Location: Egypt Posts: 21 Joined: 18.04.19 |
Dorsal view of larval head showing anterior spiracles
Abdelsalam attached the following image:  [71.01Kb] |
|
|
|
| Abdelsalam |
Posted on 20-04-2019 00:45
|
|
Member Location: Egypt Posts: 21 Joined: 18.04.19 |
Enlarged anterior spiracle
Abdelsalam attached the following image:  [32.7Kb] |
|
|
|
