 Calliphoridae bristles
|
|
| ekhohe |
Posted on 18-09-2008 20:40
|
 Member Location: Lappeenranta, Finland Posts: 291 Joined: 02.07.08 |
I really need help with these. Is my "map" correct and what are those I did not recognize? Violet = unknown (post humeral, humeral, postpronotal?) White = 2+3 acrostichal Black = 2+3 dorsocentral (if number 1 is one of these so 3+3) Red = 1+3 intra-alar Blue = 1+3 supra-alar Green = 2 postalar Gold = basal scutellar Orange = subapical scutellar Yellow = discal scutellar Light green = apical scutellar ekhohe attached the following image:  [122.87Kb] Henry http://henrys.16mb.com/ https://www.flickr.com/photos/henryekholm |
 |
|
| Tony T |
Posted on 20-09-2008 20:37
|
 Member Location: New Brunswick, Canada Posts: 662 Joined: 08.02.07 |
There are a couple of images in the general Foruns - Overviews, including this one HERE see if they help |
|
|
|
| ekhohe |
Posted on 21-09-2008 07:27
|
|
Member Location: Lappeenranta, Finland Posts: 291 Joined: 02.07.08 |
Thanks Tony, I'll study that and your other excellent photo's.
Henry http://henrys.16mb.com/ https://www.flickr.com/photos/henryekholm |
|
|
|
