View Thread
Diptera.info :: Identification queries :: Diptera (eggs, larvae, pupae)
Who is here? 1 guest(s)
 Print Thread
Puparium of Liriomyza? (from 17th century latrine Denmark)
dxj616
#1 Print Post
Posted on 29-01-2022 06:07
Member

Location:
Posts: 21
Joined: 22.11.21

Hello

Can anyone confirm if this puparium is from the tomato leaf miner (Liriomyza bryoniae)? Millimeter scale on left.
dxj616 attached the following image:


[40.14Kb]
Edited by dxj616 on 29-01-2022 06:12

dxj616
#2 Print Post
Posted on 29-01-2022 06:08
Member

Location:
Posts: 21
Joined: 22.11.21

other side
dxj616 attached the following image:


[42.8Kb]

dxj616
#3 Print Post
Posted on 29-01-2022 06:08
Member

Location:
Posts: 21
Joined: 22.11.21

spiracles
dxj616 attached the following image:


[56Kb]

dxj616
#4 Print Post
Posted on 29-01-2022 06:08
Member

Location:
Posts: 21
Joined: 22.11.21

spiracles
dxj616 attached the following image:


[47.58Kb]

dxj616
#5 Print Post
Posted on 30-01-2022 16:36
Member

Location:
Posts: 21
Joined: 22.11.21

After taking a closer look in a better microscope I am now pretty sure it is Liriomyza nietzkei.

John v
#6 Print Post
Posted on 31-01-2022 22:18
User Avatar

Member

Location: Iowa, USA
Posts: 11
Joined: 08.10.21

How are you able to determine the species of this agromyzid using the puparium stage alone? Are you using characteristics of the spiracles? Just curious.

https://bugguide.net/user/view/43382
dxj616
#7 Print Post
Posted on 01-02-2022 01:44
Member

Location:
Posts: 21
Joined: 22.11.21

Yes, I found figures of the spiracles in the reference below (Spencer named it in 1973) and compared the specimen with the spiracles of all the Liriomyza species I could find in the litterature. Several could also be excluded as they are neotropical and not found here etc. Liriomyza nietzkei was the closest match by far although I haven't been able to find figures of the spiracles from all the species in the genus. The specimen was found in a latrine so it also seems logical that it probably has something to do with food - Liriomyza nietzkei is a pest of onions and leek so it seems likely on that account as well.


Hering EM, 1957. Die Larven der Agromyziden (Diptera). 3. - Tijdschrift voor Entomologie 100: 73-94

John v
#8 Print Post
Posted on 02-02-2022 21:30
User Avatar

Member

Location: Iowa, USA
Posts: 11
Joined: 08.10.21

Very interesting, thanks for the explanation. I have spent a good deal of time attempting to photograph posterior spiracles of puparia in various families as part of my studies of stem-dwelling insects. Unfortunately I don't have access to a good dissecting scope or similarly high-powered magnifying tool to really dive into the intricacies; the most detailed spiracle photos I get are a bit less zoomed-in than what you posted here. Best of luck with your latrine fauna investigations - it sounds like an intriguing line of study.

https://bugguide.net/user/view/43382
dxj616
#9 Print Post
Posted on 04-02-2022 12:21
Member

Location:
Posts: 21
Joined: 22.11.21

Taking good pictures of the spiracles is always hard. Even a slight adjustment of the specimen or the angle of the light source can make a huge difference. The ones posted here of the spiracles are 100x magnification, which is the limit of my stereoscope, and you can just barely see the papillae on one of the pictures.

Thanks, good luck with your studies as well.
Edited by dxj616 on 04-02-2022 12:23
